Technical Data:
|
Model
|
YJSS-10A
|
YJSS-20A
|
YJSS-30A
|
|
Maximum charge current
|
10A
|
20A
|
30A
|
|
Maximum discharge current
|
10A
|
10A
|
10A
|
|
System voltage
|
12/24V
|
||
|
Max Solar Input
|
41V
|
||
|
The
battery type
|
Lead acid battery
|
||
|
Folat
|
13.7V (adjustable range 12.7-15 V)
|
||
|
Discharge stop
|
10.7V (adjustable range 9-11.3 V)
|
||
|
Disstarge reconnect
|
12.6V
(adjustable range 11.5-13 V)
|
||
|
Standby current
|
10mA
|
||
|
USB output
|
5V/2A
|
||
|
Temperature compensation
|
-24mv/°C,-48mv/°C,, Relative to
12V/24V system.
|
||
|
Operating temperature
|
-20 ～+55℃
|
||
|
Product Size(mm)/Weight(g)
|
133*70*35mm/160g
|
||
|
Packing size(mm)
|
560*410*220mm
|
||
|
Packing quantity(pcs)
|
100
|
||
